45° Male NPT Elbow
CONNECTS FRACTIONAL TUBE TO FEMALE NPT THREAD
| Part No. |
Tube O.D. (in) |
Tube O.D. (mm) |
T (NPT) |
D (mm) |
O Min (in) |
O Min (mm) |
A (in) |
A (mm) |
B (mm) |
l (mm) |
L (mm) |
L1 (mm) |
h (mm) |
H (mm) |
| ALBM 2-2N |
1/8 |
3.17 |
1/8 |
2.4 |
1/2 |
12.70 |
7/16 |
11.11 |
12.70 |
15.24 |
15.77 |
22.38 |
16.51 |
| ALBM 4-2N |
1/4 |
6.35 |
1/8 |
4.82 |
1/2 |
12.70 |
9/16 |
14.28 |
15.24 |
17.78 |
17.27 |
24.63 |
16.51 |
| ALBM 4-4N |
1/4 |
6.35 |
1/4 |
4.82 |
1/2 |
12.70 |
9/16 |
14.28 |
15.24 |
17.78 |
17.27 |
24.63 |
21.08 |
| ALBM 6-2N |
3/8 |
9.52 |
1/8 |
4.82 |
5/8 |
15.87 |
11/16 |
17.46 |
16.76 |
19.30 |
20.57 |
27.94 |
18.28 |
| ALBM 6-4N |
3/8 |
9.52 |
1/4 |
7.11 |
5/8 |
15.87 |
11/16 |
17.46 |
16.76 |
19.30 |
20.57 |
27.94 |
22.86 |
| ALBM 6-6N |
3/8 |
9.52 |
3/8 |
7.11 |
13/16 |
20.64 |
11/16 |
17.46 |
16.76 |
19.30 |
21.84 |
29.21 |
24.13 |
| ALBM 8-6N |
1/2 |
12.70 |
3/8 |
9.65 |
13/16 |
20.64 |
7/8 |
22.22 |
22.86 |
21.84 |
21.84 |
32.00 |
24.13 |
| ALBM 8-8N |
1/2 |
12.70 |
1/2 |
10.41 |
13/16 |
20.64 |
7/8 |
22.22 |
22.86 |
21.84 |
21.84 |
32.00 |
28.95 |
| ALBM 12-12N |
3/4 |
19.05 |
3/4 |
15.74 |
1-1/8 |
28.58 |
1-1/8 |
28.58 |
24.38 |
21.84 |
23.87 |
34.03 |
30.98 |
| ALBM 16-16N |
1 |
25.40 |
1 |
22.35 |
1-3/8 |
34.93 |
1-1/2 |
38.10 |
31.24 |
26.41 |
28.19 |
40.38 |
37.84 |
